Raspet Tiger Shark: Engineers Caden Teer and Peter McKinley applying ice shapes to wings. (photo by Megan Bean / © Mississippi State University)

Mississippi State engineers in the university’s Raspet Flight Research Laboratory are spearheading research that could make unmanned aircraft systems operational by the U.S. government as well as civilian aviation in icy conditions.

MSU is leading an icing system development and technology team in what the U.S. Department of Defense hopes will result in lightweight anti-icing systems, leading to certification for UAS to operate in forecasted icing conditions. The DOD recently awarded $5 million for this effort that also includes the university’s aerospace engineering department and several industry partners.

The entire team is evaluating the use of a new carbon-nanotube coating, part of an intelligently controlled ice protection system. One aspect of the flight testing  includes 3-D printed ice shapes designed by Raspet to mimic frozen formations affixed to the wings. Results from those tests help inform the development of the ice protection system.

“Our innovative approach allows us to replicate the most severe in-flight icing conditions without traveling to cold and remote areas,” said Tom Brooks, Raspet interim director. “This allows us to conduct nearly unlimited test flights at a much lower cost and generate the data we need to develop effective, low-cost and retrofittable anti-icing system solutions for use on today’s sophisticated unmanned aircraft.”

NASA-designed sophisticated software models predict the shapes, and test flights are conducted, assessing these shapes’ impact on aerodynamic performance. Icing increases drag, reduces lift and adds weight to aircraft.

“As ice builds on the wings, a process scientists refer to as ice accretion negatively impacts the aerodynamics of the wing,” Brooks said. “Raspet’s application of these 3D-printed shapes to aircraft wings enables our researchers to validate the computer modeling used to predict changes in lift and controllability caused by the ice.”

Today’s traditional ice countering technologies used on commercial and private airplanes, such as antifreeze pumps to spray the wings or inflatable bladders expanded on wing sections to dislodge ice, are too heavy and energy intensive to work on UAS. The newly developed coating for UAS has extremely high heat conductivity, allowing it to transfer warmth from small heat strips on the wings’ leading edges to counter ice formation.

If proven successful, the ice protection system, which is retrofittable to existing aircraft and easy to install, would also be of much interest in the civilian aviation industry, Brooks explained.

“Because it’s easy and inexpensive to install on existing aircraft, this lightweight anti-icing system has tremendous potential for use in general aviation,” he said.

Raspet’s two state-of-the-art TigerShark Block 3 XP aircraft support the project, weighing about 350 pounds, carrying nearly 100 pounds of payload and flying for 8-12 hours before refueling. The MSU laboratory also has worked with MSU Professor of Aerospace Engineering David Thompson, a well-known expert in aircraft icing, to create the 3-D predicted-shape models.

 Other Raspet partners include Ohio’s private, nonprofit Battelle Memorial Institute, Kansas’ Ultra Electronics subsidiary ICE Inc., and Pennsylvania’s Navmar Applied Science Corporation.
